Description
The ifm TA series are programmable 2-wire temperature transmitters designed to accept RTD (Pt100/Pt1000) or thermocouple inputs from a temperature sensor and convert them to a linearized 4–20 mA analog signal for PLC/SCADA analog input cards. Models such as TA2002 (standard programmable via PC/keypad), TA1602/TA1605/TA1612 (compact/economy versions), and TA2012/TA2105/TA2107 (enhanced features, HART optional on some) cover a wide range of process temperature monitoring applications in food & beverage, pharma, water treatment, and machine building.
Key Features
- Input: Pt100 (2/3/4-wire), Pt1000, Ni100, Thermocouple types J/K/T (model dependent — check suffix)
- Output: 4–20 mA (2-wire loop-powered, 24V DC loop required)
- Configuration: Via ifm “moneo” / LR DEVICE software over IO-Link (on smart versions) or built-in 3-button keypad + LCD (TA2002/TA2012)
- Measuring Range: User-programmable (e.g., -50…+150 °C or any span within sensor limits)
- Accuracy: Typically ≤ ±0.1 % of span + sensor error
- Sensor Break / Wire Break Detection: Yes — drives output to < 3.6 mA or > 22 mA on fault
- Country of Origin: Germany
Model Reference Table
Model | Display / Keypad | Config Method | Input Types | Typical Use |
|---|---|---|---|---|
TA2002 | LCD + 3 buttons | Keypad or PC (LR DEVICE) | Pt100/1000, Ni100, TC (J/K/T) | General purpose, field-adjustable |
TA2012 | LCD + buttons (enhanced) | Keypad / PC / IO-Link (select var.) | Pt100/1000, Ni100, TC | With IO-Link or HART option |
TA1602 | LED (no LCD) | PC only (LR DEVICE) | Pt100 (mostly) | Cost-optimized, DIN B-head mount |
TA1605 | LED (no LCD) | PC only | Pt100/Pt1000 | Compact, programmable via software |
TA1612 | LED (no LCD) | PC only | Pt100/Pt1000, TC | Extended input range vs TA1605 |
TA2105 | LED or small LCD | Keypad + PC | Pt100/1000, TC | Mid-range with local setpoint |
TA2107 | Small LCD + buttons | Keypad + PC | Pt100/1000, TC | Similar to TA2105 with display |
💡 Selection Tips:
Technical Specifications (Representative — TA2002 Programmable Transmitter)
Parameter | Specification |
|---|---|
Model | TA2002 (ifm Electronic) |
Sensor Input | Pt100 (−200…+850 °C), Pt1000, Ni100, Thermocouple J/K/T (per selected variant) |
Output Signal | 4–20 mA (2-wire, loop-powered) |
Supply Voltage (Loop) | 12–30 V DC (typical 24 V DC in loop) |
Programmable Span | Any span within sensor limits (e.g., 0…100 °C, -50…+150 °C) |
Accuracy | ≤ ±0.1 % of selected span + sensor tolerance |
Temperature Drift | ≤ ±0.01 % of span / °C |
Response Time (τ₆₃) | < 1 s (typical analog update rate) |
Sensor Break Detection | Output < 3.6 mA (down-scale) or > 22 mA (up-scale) — selectable |
Configuration | 3-button keypad on front + LC display OR via PC (ifm LR DEVICE / moneo) |
Electrical Connection | Screw terminals (for sensor & loop) — DIN B head mount version has terminal block inside head |
Mounting | DIN B connection head (Ø6 mm probe stem compatible) or panel mount (per variant) |
Operating Temp. (Electronics) | -25 … +70 °C (non-condensing) |
Protection | IP65 (when mounted in properly sealed head) |
Standards | CE, UL (component recognized), RoHS |
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty (where offered)
- Technical support for:
- Input type selection (Pt100 2/3/4-wire — recommend 3-wire for best accuracy/cost)
- Span & zero setting (via keypad or LR DEVICE software)
- Loop wiring (2-wire 4–20 mA to PLC analog input — include 250 Ω shunt if PLC lacks internal)
- Fault indication interpretation (sensor break → <3.6 mA or >22 mA)
- Cross-reference vs. WIKA T91 / Endress+Hauser iTEMP / Honeywell STT series
Delivery Time
- Standard delivery: 3-5 working days (stock items)
- Express shipping available upon request
Why Choose Our Store
- Genuine ifm Electronic temperature transmitters
- Global supply network with competitive pricing
- Expertise in temperature measurement & analog signal conditioning
- Comprehensive technical documentation (wiring diagrams, LR DEVICE quick-start, RTD vs TC application note)
- Responsive customer service and support
Applications
- Process temperature monitoring (water, steam, glycol, oil)
- Food & beverage (CIP/SIP tank temperature — with hygienic probe + TA series in DIN head)
- Pharma / biotech (validated temp. loops with traceable calibration)
- Machine tool coolant / hydraulic oil temperature
- Retrofit of bare RTD/TC probes to 4–20 mA analog loops
