Description
The Omron CP1W-MAB221 is an analog input/output option board designed for the CP1E/CP1L/CP1H series programmable logic controllers (PLCs). This compact module provides flexible analog signal conditioning, allowing precise measurement and control of voltage or current signals in industrial automation applications. With easy mounting on the CPU unit and straightforward configuration via PLC programming, it offers a cost-effective solution for adding analog functionality to small-scale control systems.
Key Features
- Module Type: Analog Input/Output Option Board
- Compatible PLCs: CP1E, CP1L, CP1H series
- Analog Inputs: 2 channels (voltage/current switchable)
- Analog Outputs: 2 channels (voltage/current switchable)
- Input Range: 0-5 V DC, 1-5 V DC, 0-10 V DC, -10 to 10 V DC, 0-20 mA, 4-20 mA
- Output Range: 0-5 V DC, 1-5 V DC, 0-10 V DC, -10 to 10 V DC, 0-20 mA, 4-20 mA
- Resolution: 1/6000 (full scale)
- Accuracy: ±0.3% full scale (25°C)
- Conversion Speed: 10 ms per channel (input and output)
- Isolation: Photocoupler isolation between I/O and PLC
- Country of Origin: Omron Standard (China/Japan)
Technical Specifications
Parameter | Specification |
|---|---|
Model | CP1W-MAB221 |
Input Channels | 2 |
Output Channels | 2 |
Input Signal Range | Voltage: 0-5 V, 1-5 V, 0-10 V, -10 to 10 V Current: 0-20 mA, 4-20 mA |
Output Signal Range | Voltage: 0-5 V, 1-5 V, 0-10 V, -10 to 10 V Current: 0-20 mA, 4-20 mA |
Resolution | 1/6000 |
Accuracy | ±0.3% full scale (at 25°C) |
Conversion Speed | 10 ms/channel (inputs and outputs) |
Isolation | Photocoupler isolation (I/O to PLC) |
Power Consumption | 5 V DC (from PLC unit) |
Operating Temperature | -10°C to +55°C |
Storage Temperature | -25°C to +70°C |
Dimensions (W x H x D) | 34 x 65 x 55 mm |
Weight | Approx. 120 g |
Standards | CE, UL, cULus, RoHS |
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty
- Technical support for wiring, configuration, and integration with CP1 series PLCs
- Compatibility verification with your existing PLC system
- Programming assistance for analog scaling and signal processing
- Documentation: Full datasheets, manuals, and wiring diagrams provided
Delivery Time
- Standard delivery: 3-5 working days
- Express shipping available upon request
- Bulk order discounts available
Why Choose Our Store
- Genuine Omron automation components
- Global supply network with competitive pricing
- Expertise in CP1 series PLC systems and analog modules
- Comprehensive technical documentation and software support (CX-Programmer)
- Responsive customer service and after-sales support
Applications
- Process Control: Temperature, pressure, and flow control
- HVAC Systems: Analog sensor monitoring and actuator control
- Industrial Machinery: Speed control, position feedback, and level measurement
- Water Treatment: pH monitoring, chemical dosing, and pump control
- Packaging Machines: Tension control and analog setpoint adjustment
