Description
The listed TM221C24R, TM221CE40R, TWDFCW30K, TCSMCNAM3M002P, TWDFCW30M, TWDFCW50K are Schneider Electric Modicon M221 (Easy M221) Programmable Logic Controllers and SoMachine / EcoStruxure Machine Expert – Basic (formerly SoMachine Basic) accessories.
- TM221C24R → Modicon M221 Controller, 24 I/O (14 × 24V DC Sink/Source Inputs + 10 × Relay Outputs 2A/point), No embedded analog, 1 × RJ45 Ethernet port (Modbus TCP + programming), 1 × Mini-USB port (programming / HMI link), SD Card slot (for backup/log), Spring terminal (C = spring clamp; S = screw — C24R = spring), Rated supply 100–240V AC or 24V DC? Actually TM221C24R = AC supply (100–240V AC) — R suffix = Relay outputs; if DC supply version it would be TM221C24DR (24V DC in) — check: Schneider naming: TM221 C 24 R → C=Spring terminal, 24=I/O count, R=Relay outputs — Power: AC supply (85–264V AC) standard on non-D versions; DC supply = add D before R e.g. TM221CD24R = 24V DC in, spring, 24 I/O, relay out).
- TM221CE40R → M221 40 I/O version (24 DI + 16 DO Relay — or 24 DI + 16 Relay typical for CE40R — actually CE40R = 40 I/O: 24 × 24V DC inputs + 16 × Relay outputs 2A, Spring terminal, AC supply, Ethernet + USB, SD slot — expanded I/O count over C24R). “E” in some regions denotes Ethernet included (all M221 have Ethernet — E just regional packaging diff; CE40R = 40 I/O relay AC supply spring).
- TWDFCW30K / TWDFCW30M / TWDFCW50K → Programming / PC Connection Cables for Schneider PLCs (Twido / M221 / M241 via USB) — TWDFCW30K = USB A to Mini-B (for M221 USB port — same as printer cable! Actually TWDFCW30K = USB cable type A-B for Twido/M221/M241 — length 3m “K” maybe region code; TWDFCW30M = 3m; TWDFCW50K = 5m). These are standard USB 2.0 A-to-Mini-B cables — any quality Mini-B USB cable works but Schneider p/n ensures spec compliance.
- TCSMCNAM3M002P → **Serial (RS-232/RS-485) Communication Cable — Schneider Modicon / Twido / M221 — Mini-DIN to DB9 or terminal block? Actually TCSMCNAM3M002P = Modicon to PC serial cable (RJ45? Wait: TCSMCNAM3M002P = TSXPCX1031 (legacy) replacement — “CNAM3M002P” = CANopen? No — check: Schneider cable for M221 serial port (if used) — M221 has RJ45 Modbus RTU port (Serial) + Ethernet + USB. TCSMCNAM3M002P is the RJ45 to DB9 Female (Straight through for Modbus RTU / ASCII to PC COM port or HMI) — 2m length. Used to connect M221 Serial RJ45 port → PC RS-232 (DB9) or 3rd party device.
The Modicon M221 is part of the Easy Logic Controller range (successor to Twido TWDLCAE series in small apps) — programmed with EcoStruxure Machine Expert – Basic (free download from Schneider — formerly SoMachine Basic). It targets stand-alone machines, small packaging, pump/fan control — up to 240 I/O with expansion (TM2… expansion modules — TM2AMI2LT / TM2DDI… etc. — M221 supports up to 7 TM2 expansion modules on right-side bus).
Key Features (TM221C24R)
- I/O: 14 × 24V DC Digital Inputs (Sink/Source — 10k–30V DC range, 2 high-speed counter inputs capable up to 100 kHz on I0/I1 typically), 10 × Relay Outputs (NO — 2A resistive / 250V AC or 30V DC — common per 4 pts typically: Out 0–3 = COM0; Out 4–7 = COM1; Out 8–9 share COM2? Check manual — C24R has 3 commons for 10 relay outputs)
- Communication: 1 × Ethernet RJ45 (Modbus TCP, Machine Expert programming), 1 × Serial RJ45 (Modbus RTU Master/Slave ASCII), 1 × Mini-USB (programming & local HMI link — no driver install needed on Win10+)
- Memory: 16 MB program + data (symbolic programming supported), recipe, data logging to SD
- SD Card Slot: For program backup, data logging, firmware update (SDHC up to 32GB — Schneider recommends specific cards like TSXSAC64K / TSXSAC128K — but standard SDHC often works)
- Expansion: Up to 7 TM2 series I/O modules (analog, more DI/DO, thermocouple, etc.) on right-side expansion bus
- Country of Origin: France / China (Schneider Electric)
Model & Variant Reference (Modicon M221 & Listed Accessories)
Model | Type | Key Spec | Best For |
|---|---|---|---|
TM221C24R (listed) | M221 CPU — 24 I/O | 14 DI 24V DC + 10 DO Relay (2A) — Spring term — AC supply — Eth+USB+Ser | Small machine — relays drive contactors/SSR directly; enough DI for sensors |
TM221CE40R (listed) | M221 CPU — 40 I/O | 24 DI 24V DC + 16 DO Relay — Spring — AC supply — Eth+USB+Ser | More I/O in base — less expansion needed |
TM221CD24R | M221 CPU — 24 I/O (DC supply 24V DC in) | Same I/O as C24R but 24V DC powered (for cabinet with 24V DC only) | Cabinet with only 24V DC PSU |
TWDFCW30K / TWDFCW30M | USB Programming Cable (A to Mini-B) | 3 m length — connects PC USB → M221 Mini-USB port | Programming / online monitoring |
TCSMCNAM3M002P | Serial (Modbus RTU) Cable | RJ45 (M221 Serial port) → DB9 Female (PC COM or HMI) — 2 m | Connect to PC serial port for legacy download or Modbus RTU device |
TM2AMI2LT | M221 Expansion — 2 ch Analog In (0–10V/4–20mA) | Optional — shows expandability | Add analog sensing if C24R lacks onboard analog |
⚠️ Critical Notes:
.SMB. NOT compatible with Unity Pro / Control Expert (those are for Premium / M340/M580). TwidoSoft (old Twido SW) can sometimes import to SoMachine Basic for migration.
Technical Specifications (TM221C24R — Modicon M221, 14 DI 24V DC + 10 DO Relay, Spring Term, AC Supply, Ethernet/USB/Serial)
Parameter | Specification |
|---|---|
Model / Order Code | TM221C24R (Schneider Electric Modicon M221 Logic Controller) |
Series | Modicon M221 (Easy Logic Controller — successor to Twido TWDLCAE) |
Built-in I/O | 14 × Digital Inputs (24V DC Sink/Source — 10…30V DC range; 2 inputs usable as 100 kHz high-speed counter / PTO) ; 10 × Relay Outputs (NO — 2A resistive @250V AC / 30V DC — grouped commons: typ. COM0=Q0–Q3, COM1=Q4–Q7, COM2=Q8–Q9) |
Power Supply (Controller) | 100–240 V AC (85–264 V AC, 47–63 Hz) — this is determined by absence of “D” after C24: TM221C24R = AC in; TM221CD24R = 24V DC in |
Communication Ports | 1 × Ethernet RJ45 10/100 Mbps (Modbus TCP, programming); 1 × Serial RJ45 (Modbus RTU Master/Slave, ASCII); 1 × Mini-USB (programming & local HMI link — auto-enumerates as virtual COM in Machine Expert) |
Programming Software | EcoStruxure Machine Expert – Basic (free — formerly SoMachine Basic) — project .SMB |
User Memory | 16 MB (program + symbols + data + recipes + file system for SD) |
SD Card Slot | Yes — supports SD/SDHC up to 32 GB (for program clone, data log, firmware update — Schneider recommends TSXSAC64K/128K) |
Max. Expansion I/O (TM2) | Up to 7 TM2 modules (add DI/DO/AI/AO/TC/RTD/Encoder — e.g., TM2AMI2LT, TM2DAI2LT, TM2DDI16DK etc.) |
Backup | Retentive variables (set in SW); program retained in flash — auto-load on power-up; SD card for clone/backup |
Indicators (LED) | PWR (green — supply OK), RUN (green — in RUN mode), ERR (red — fault), I/O LEDs per DI/DO, COM (Ethernet activity), SER (Serial activity) |
Operating Temp. | -10 … +55 °C (no condensation / icing) |
Dimensions (W×H×D) | 90 mm (W) × 100 mm (H) × 70 mm (D) — DIN rail mount (35 mm top hat) |
Weight | ~ 0.29 kg |
Standards | CE, UL, cUL, CSA, KC, RCM, RoHS, REACH |
Included Accessories | Removable terminal block (spring), quick-start guide — programming cable & SD card NOT included |
Country of Origin | France / China (Schneider Electric) |
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty (power-up + forced I/O toggle via Machine Expert – Basic monitor)
- Technical support for:
- Software install & first project (download EcoStruxure Machine Expert – Basic → new project → select TM221C24R → assign I/O → simple coil → download via USB)
- I/O wiring (DI: 24V DC sink/source — one side of sensor to +24V, other to I□; DO Relay: COM to AC Line/L+ 24V, NO to load, NC unused — observe common grouping & rating)
- PSU type confirmation (C24R = AC supply 100–240V AC; CD24R = 24V DC in — verify your cabinet)
- Expansion module selection (TM2AMI2LT 2AI, TM2DAI2LT 2AO, TM2DDI16DK 16DI etc. — up to 7)
- Ethernet / Modbus TCP setup (assign static IP — default often DHCP off / 192.168.1.10? Check — can set in SW or via USB first time)
- Cable / SD card recommendation (TWDFCW30K USB A-MiniB; TCSMCNAM3M002P for serial; TSXSAC64K 64GB SDHC)
- Twido (TWDLCAE) → M221 migration note (import TwidoSoft project into Machine Expert – Basic — partial conversion; some instructions differ)
- Optional: TM221CD24R (24V DC in ver.), TM2 expansion modules (TM2AMI2LT etc.), USB cable TWDFCW30K/TWDFCW50K, Serial cable TCSMCNAM3M002P, SD card TSXSAC64K, 24V DC PSU (ABL2/ABL8 series)
Delivery Time
- Standard delivery: 3-5 working days (stock items)
- Express shipping available upon request
Why Choose Our Store
- Genuine Schneider Electric Modicon M221 — not clone (firmware integrity / Ethernet PHY critical)
- Global supply network with competitive pricing
- Expertise in Schneider M221 system (PSU type AC vs DC, TM2 expansion, Machine Expert – Basic commissioning, Twido migration)
- Comprehensive technical documentation (I/O terminal diagram, Machine Expert first-connect screenshot, TM2 expansion bus pic, Ethernet IP set steps)
- Responsive customer service and support
Applications
- Small Standalone Machine: Packaging / labeling / capping — 14 DI (sensors) + 10 relay DO (contactors/SSR/pilot lamps) — enough for simple sequencer.
- Pump / Fan Control (Building / Water): Relay outputs switch pumps/contactors; Ethernet for remote supervision via SCADA/MES over Modbus TCP.
- Retrofit Twido TWDLCAE: Drop-in logic upgrade — more memory, Ethernet onboard, free SW — import old Twido project (partial auto-convert).
- OEM Skid / Test Rig: USB programming convenient; SD card for recipe / clone to multiple skids.
- With Expansion: Add TM2 analog for temperature (TM2AMI2LT) or more DI/DO — flexible scale-up within M221 family.
