The SICK TMS61B-PCH360 is a high-performance inertial sensor designed for precise motion detection and position tracking in industrial automation applications. This sensor combines accelerometer and gyroscope technologies to deliver accurate measurement of linear acceleration, angular rate, and orientation changes. With its robust housing and IP67 protection rating, it operates reliably in demanding environments including mobile machinery, robotics, and material handling systems. The sensor features CANopen interface for seamless integration and provides real-time data for stability control, navigation, and safety applications.
Key Features
- High-precision inertial measurement unit (IMU)
- 3-axis accelerometer and gyroscope
- CANopen communication interface
- IP67 rated for harsh environments
- Wide operating temperature range
- Compact and rugged housing design
- Real-time motion data output
- Easy mounting and installation
- OEM version available
Technical Specifications
Parameter | Specification |
|---|---|
Model Number | TMS61B-PCH360 |
Sensor Type | Inertial Measurement Unit (IMU) |
Accelerometer Range | ±2g/±4g/±8g/±16g (selectable) |
Gyroscope Range | ±125°/s to ±2000°/s (selectable) |
Communication | CANopen (CiA 410) |
Power Supply | 9-32V DC |
Power Consumption | <2.5W |
Operating Temperature | -40°C to +85°C |
Protection Rating | IP67 |
Housing Material | Aluminum |
Dimensions | 61 x 45 x 30 mm |
Weight | Approx. 150g |
Mounting | 4x M4 threaded holes |
Vibration Resistance | 10g (10-2000 Hz) |
Shock Resistance | 100g (6ms) |
Warranty & After-Sales
- Factory New Units: 12 months warranty
- Second-Hand Units: 3-6 months warranty
- Technical Support: Configuration and integration assistance
- Repair Services: Component-level repair and calibration
- Compatibility Verification: Ensured compatibility with control systems
Delivery Information
- Standard Delivery: 3-5 working days
- Express Shipping: Available upon request
Why Choose Us
- KaiRock Verified: Quality tested and certified
- Genuine Components: Authentic SICK products
- Global Supply: Competitive pricing with worldwide shipping
- Expert Support: Professional technical assistance
Applications
- Mobile machinery stability control
- Robotic navigation and positioning
- Agricultural equipment guidance
- Construction vehicle safety systems
- Material handling equipment
- Marine navigation systems
- Industrial automation safety
