The Siemens 5SL6104-7CC is a high-performance single-pole miniature circuit breaker (MCB) from the SENTRON series. Designed for reliable protection of electrical installations, this MCB is rated at 4 A with a 6 kA breaking capacity. It features a Type C tripping characteristic, making it ideal for circuits with moderate inrush currents, such as those found in residential and light commercial applications. The device provides robust protection against overloads and short circuits, ensuring the safety of electrical systems and connected equipment.
Key Features
- Miniature Circuit Breaker (MCB) with Type C tripping characteristic
- Rated Current: 4 A
- Breaking Capacity: 6 kA (IEC 60898-1)
- Operating Voltage: 230/400 V AC
- Poles: 1 (Single-pole)
- Mounting: DIN rail compatible
- Protection Class: IP20
- Energy Limiting Class: 3
- Country of Origin: Turkey
Technical Specifications
Parameter | Specification |
|---|---|
Model Number | 5SL6104-7CC |
Product Type | Miniature Circuit Breaker (MCB) |
Rated Current (In) | 4 A |
Tripping Characteristic | Type C |
Rated Voltage | 230/400 V AC |
Insulation Voltage | 440 V |
Rated Short-Circuit Breaking Capacity (Icn) | 6 kA (EN 60898) |
Rated Ultimate Short-Circuit Breaking Capacity (Icu) | 30 kA (IEC 60947-2) |
Frequency | 50/60 Hz |
Number of Poles | 1 |
Mechanical Endurance | 10,000 operations |
Operating Temperature | -25°C to +55°C |
Storage Temperature | -40°C to +75°C |
Dimensions (H x W x D) | 90 mm × 18 mm × 76 mm |
Installation Depth | 70 mm |
Weight | Approx. 120 g |
Connectable Conductor Cross-Section | 0.75–35 mm² (solid/stranded) |
Tightening Torque | 2.5–3.5 N·m |
Standards | EN 60898, IEC 60947-2, RoHS compliant |
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty
- Technical support for circuit design and protection coordination
- Wiring and installation assistance
- Compatibility verification with existing distribution boards
Delivery Time
- Standard delivery: 3-5 working days
- Express shipping available upon request
Why Choose Our Store
- Genuine Siemens components
- Global supply network with competitive pricing
- Expertise in electrical protection systems
- Comprehensive technical documentation
- Responsive customer service and support
Applications
- Branch circuit protection in residential buildings
- Lighting circuits in offices and commercial spaces
- Protection of control devices and sensitive electronics
- Small inductive loads with moderate inrush currents
- General-purpose socket outlets and power distribution
