Description
The SICK WTT12L-B2542 Photoelectric Proximity Sensor is a high-performance laser-based proximity sensor designed for industrial automation applications. This sensor utilizes time-of-flight (ToF) technology with a Class 1 visible red laser source, providing reliable object detection with a sensing range of 100 mm to 1,800 mm. Featuring background suppression function and compact design, it offers precise detection of objects regardless of surface color or reflectivity. With M12 5-pin connector, IP67 protection rating, and operating temperature range from -35°C to +50°C, this sensor is suitable for harsh industrial environments. It supports both PNP and NPN output configurations and provides fast response times for high-speed applications.
Key Features
- Photoelectric Proximity Sensor with laser technology: Utilizes advanced laser ToF for precise measurement.
- Sensing Range: 100 mm to 1,800 mm, ideal for medium to long-range detection.
- Laser Source: Class 1 visible red laser (658 nm), safe and easy to align.
- Detection Principle: Time-of-flight (ToF) with background suppression, eliminating background interference.
- Output Configuration: PNP/NPN (selectable), offering flexible integration with different control systems.
- Connection: M12 5-pin connector for quick and reliable installation.
- Protection Rating: IP67, ensuring protection against dust and water ingress.
- Operating Temperature: -35°C to +50°C, suitable for extreme conditions.
- Response Time: ≤ 16.7 ms, enabling use in high-speed applications.
- Country of Origin: Germany, representing high manufacturing standards.
Technical Specifications
- Model: WTT12L-B2542
- Supply Voltage: 10-30 V DC
- Current Consumption: ≤ 70 mA
- Output Type: PNP/NPN (push-pull)
- Output Current: ≤ 100 mA
- Switching Frequency: 30 Hz
- Light Source: Visible red laser
- Wavelength: 658 nm
- Laser Class: Class 1 (IEC 60825-1)
- Housing Material: Plastic (VISTAL®)
- Dimensions: 20 mm × 49.6 mm × 44.2 mm (W×H×D)
- Weight: approx. 48 g
- Connection Type: M12 male connector, 5-pin
- Protection Class: IP67
- Operating Temperature: -35°C to +50°C
- Storage Temperature: -40°C to +70°C
- Standards: CE, UL, RoHS compliant.
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty
- Technical support for configuration and installation
- Wiring and mounting assistance
- Compatibility verification with existing systems
- Commissioning and diagnostics support available
Delivery Time
- Standard delivery: 3-5 working days
- Express shipping available upon request
Why Choose Our Store
- Genuine SICK components
- Global supply network with competitive pricing
- Expertise in industrial automation systems
- Comprehensive technical documentation
- Responsive customer service and support
Applications
- Object detection in automated production lines
- Material handling and conveyor systems
- Packaging machinery
- Robotics and automation
- Quality control and inspection systems
- Machine safety and position monitoring
- Logistics and warehousing systems.
