Description
The Mitsubishi A1SD70 is a high-performance, single-axis position control unit designed for the MELSEC-A series PLC. It provides precise motion control for servo and stepper motor systems, making it ideal for applications such as machine tools, assembly lines, and material handling. The A1SD70 is part of a comprehensive system that includes the A1S63ADA (analog I/O), A1SJ71PT32-S3 (PROFIBUS), and the A1SX40, A1SX42, A1SX81 (digital I/O) modules, offering a complete solution for industrial automation. This system is known for its reliability, high-speed performance, and ease of integration into existing control architectures.
Key Features
- Position Control Unit: Single-axis positioning with high-speed pulse output.
- Analog I/O Module: High-resolution analog signal conversion for process control.
- PROFIBUS Module: High-speed network communication for distributed control systems.
- Digital I/O Modules: High-density input/output for discrete control signals.
- System Integration: Seamless compatibility with MELSEC-A series PLCs.
- High Reliability: Industrial-grade components designed for harsh environments.
Technical Specifications
Component | Model | Key Specifications | Details |
|---|---|---|---|
Position Control | A1SD70 | Control Type: 1 axis Output Type: Pulse train Max Speed: 400Kpps (differential driver) / 200Kpps (open collector) Data Points: 600/axis Connector: 36-pin | |
Analog I/O | A1S63ADA | Inputs: 2 channels (Voltage/Current) Outputs: 1 channel (Voltage/Current) Resolution: 12-bit Voltage Range: -10 to +10V / 0 to 5V / 1 to 5V Current Range: 0-20mA / 4-20mA | |
PROFIBUS | A1SJ71PT32-S3 | Network Type: PROFIBUS-DP Function: Master/Slave Cable Type: Twisted pair or cable Max I/O: 30 points (16I/14O) | |
Digital Input | A1SX40 | Points: 16 points Voltage: 12-24V DC Response Time: 10ms Type: Sink/source | |
Digital Input | A1SX42 | Points: 64 points Voltage: 12-24V DC Response Time: 10ms Type: Sink/source | |
Digital Input | A1SX81 | Points: 64 points Voltage: 24V DC Response Time: 10ms Type: Sink/source |
General System Specifications:
- Supply Voltage: 24V DC
- Protection Rating: IP20 (standard for control cabinet use)
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -25°C to 75°C
- Compliance: CE, UL, RoHS
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty
- Technical support for configuration and installation
- Wiring and mounting assistance
- Compatibility verification with existing systems
- Commissioning and diagnostics support available
Delivery Time
- Standard delivery: 3-5 working days
- Express shipping available upon request
Why Choose Our Store
- Genuine Mitsubishi components
- Global supply network with competitive pricing
- Expertise in industrial automation systems
- Comprehensive technical documentation
- Responsive customer service and support
Applications
- CNC machines and machine tools
- Robotics and pick-and-place systems
- Packaging machinery and material handling
- Process control and data acquisition
- Factory automation and distributed control
