Description
The E-T-A 9000-41034-0401000 is an electronic circuit protection module from the E-TA 9000 Series (Micro Electronic Circuit Protector / Electronic Circuit Breaker), designed to replace thermal-magnetic breakers in DC control circuits. Unlike fuses or thermal breakers, it offers precise adjustable current trip, instantaneous electronic disconnection (no thermal delay for overload — follows I²t characteristic but trips faster than thermal), remote reset/switching via control input, and status output for PLC monitoring.
Based on the part number breakdown:
- 9000 → E-T-A 9000 Series electronic circuit protector
- 41034 → Specific base/module type — 1-channel, DIN-rail mount, screw terminals, 24 V DC rated (typical for 41034 base)
- 0401 → Trip Current = 4.0 A (adjustable — most 9000 series have potentiometer or are factory-set; “0401” in E-T-A 9000 coding often = 4.0A range/setting)
- 000 → Options (no extra features / standard — e.g., no auxiliary contact or special coating; verify exact dash)
Key advantages vs thermal MCB:
- No nuisance tripping from ambient temperature (electronic sensing)
- Adjustable trip current (some variants — pot on face; others factory-fixed)
- Remote Reset / Turn-On via control terminal (can be used as a remotely-switched protected 24V DC power distributor)
- Status Output (N.O./N.C.) — some 9000 variants provide a semiconductor or relay status contact to signal trip condition to PLC
The 9000 series is commonly used to protect 24 V DC control circuits (sensors, solenoid banks, I/O racks, comms modules) in machine panels — each branch gets its own 9000 protector so a short on one branch doesn’t drop the whole 24V PSU.
Key Features
- Rated Voltage: 24 V DC (typical — some 9000 accept 12–48 V DC — check label; 41034 base = 24V DC nominal)
- Trip Current: Adjustable or fixed — for 0401 = 4.0 A (typical range 0.5×–1.2× of rating depending on pot)
- Tripping Characteristic: Electronic — overload follows I²t; short-circuit instantaneous (< 0.5 ms for hard short)
- Manual / Remote Reset: Pushbutton on front + remote reset via control input (A1/A2 or separate terminal — see manual)
- Status Indication: LED (green = ON/powered; red = tripped) + optional status output (some versions)
- Mounting: 35 mm DIN rail (EN 60715)
- Country of Origin: Germany (E-T-A Elektrotechnische Apparate GmbH)
Model & Specification Reference (E-T-A 9000 Series Example)
Model Segment | Meaning (9000-41034-0401000 context) |
|---|---|
9000 | Series — Electronic Circuit Protector (Electronic CB) |
41034 | Base type — 1-channel, 24V DC, screw term., DIN rail, with/without status contact (verify sub-suffix) |
0401 | Trip setting = 4.0 A (adjustable pot or fixed — “04” = 4A range) |
000 | Standard version (no extra options — check exact quote for aux contact presence) |
⚠️ Important Installation & Selection Notes:
Technical Specifications (Representative — E-T-A 9000-41034-0401000, 24V DC, 4A Trip)
Parameter | Specification |
|---|---|
Model / Order Code | 9000-41034-0401000 (E-T-A Electronic Circuit Protector) |
Series | E-T-A 9000 — Electronic Circuit Breaker / Micro Electronic Circuit Protection |
Rated Operating Voltage (Ue) | 24 V DC (nominal — operating range typically 18–32 V DC for 24V type) |
Trip Current (Iₙ) | 4.0 A (adjustable if pot present; fixed if no pot — verify by -0401 code = 4A setting) |
Number of Poles / Channels | 1 (single channel — protects one 24V DC branch) |
Tripping Method | Electronic — overload follows I²t characteristic; short-circuit instantaneous (< 0.5 ms typ.) |
Reset Type | Manual pushbutton (front) + Remote reset (via control terminals — if fitted) |
Status Indication | Bi-color LED: Green = ON (supply OK, closed); Red = Tripped (open) |
Status Output (Option — check if present) | N.O. / N.C. semiconductor or micromechanical relay contact (rated ~ 30 V DC / 0.5 A) — signals trip condition |
Power Dissipation | ≤ 2 W (typical at rated load) |
Mounting | 35 mm DIN rail (EN 60715 / TH35) — width ~ 22.5 mm (standard DIN module) |
Connection | Screw terminals (accepts 0.2–2.5 mm² / AWG 24–14) |
Ambient Temp. Range | -20 … +60 °C (no icing/dewing) |
Standards | IEC 60934 (Circuit Breakers for Equipment — CB-E), CE, UL 1077 Recognized Component (some versions) |
Dimensions (W×H×D) | ~ 22.5 mm × 90 mm × 75 mm (standard DIN 435 mm height profile) |
Weight | ~ 0.08 kg |
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty (power-up + controlled overcurrent trip test — verify opens at setpoint & resets)
- Technical support for:
- Trip current setting guidance (normal load vs inrush — set ~ 110–125% of steady-state max)
- Terminal identification (power in/out, remote reset, status contact — per E-T-A 9000 manual)
- DIN rail spacing & grouping (typically 22.5 mm wide — no derating between adjacent units if well ventilated)
- Cross-ref to thermal MCB (if replacing — explain differences: no thermal memory, instant re-close after fault vs cool-down wait)
- Alternative: 9000 series with different trip (0.5A–10A range) or with auxiliary status contact (if this -000 lacks it but you need status)
- Optional DIN jumpers, marking tags
Delivery Time
- Standard delivery: 3-5 working days (stock items)
- Express shipping available upon request
Why Choose Our Store
- Genuine E-T-A 9000 series electronic protectors — not thermal MCB substitutes with wrong trip curve
- Global supply network with competitive pricing
- Expertise in circuit protection selection (thermal vs electronic, inrush consideration, status contact wiring)
- Comprehensive technical documentation (time-current curve, terminal diagram, DIN cutout)
- Responsive customer service and support
Applications
- 24V DC Control Branch Protection: Protect sensor banks, solenoid valve manifolds, I/O module power feeds — isolate faults without dropping whole 24V DC PSU.
- Machine Build / OEM: Each functional group (conveyor drives, clamps, safety devices) on its own 9000 protector — easy fault localization via LED + status contact.
- Retrofit of Thermal MCB: Replace bimetal MCBs that nuisance-trip in hot cabinets — electronic sensing immune to ambient.
- Remote Power Distribution: Use remote reset input to turn branch power on/off from PLC (acts as a protected remote-controlled 24V DC switch).
- Spare / MRO: Exact article number match for panel MRO — drop-in replacement retains trip setting (if pot-equipped — note original pot
