The DELTA EC3 Series Programmable Controllers DVP48EC00R3 and DVP48EC00T3 are high-performance, standard compact PLCs designed for mid-range automation applications. As part of the DVP-EC3 series, they offer enhanced processing power and expanded I/O capabilities. The key distinction lies in the output type: the DVP48EC00R3 features robust Relay outputs, ideal for switching AC/DC loads, while the DVP48EC00T3 utilizes fast Transistor (sink) outputs for high-speed DC switching applications. Powered by a universal 100-240V AC supply, both controllers come with built-in RS-232 and RS-485 communication ports, supporting protocols like Modbus ASCII/RTU for seamless system integration. With a larger program capacity, they are suitable for more complex control logic and sequential processes in manufacturing and material handling.
Key Features
- Standard Compact PLC with expanded I/O capacity
- I/O Configuration: 48 points (24 inputs / 24 outputs)
- Output Type: DVP48EC00R3 (Relay) / DVP48EC00T3 (Transistor – Sink)
- Power Supply: 100-240V AC
- Communication: Built-in RS-232 and RS-485 ports
- Protocol Support: Modbus ASCII/RTU, PLC Link
- Program Capacity: 16k steps
- High-Speed Processing: Suitable for complex control tasks
- Country of Origin: Taiwan
Technical Specifications
Parameter | DVP48EC00R3 | DVP48EC00T3 |
|---|---|---|
Supply Voltage | 100-240V AC (±10%), 50/60 Hz | 100-240V AC (±10%), 50/60 Hz |
Input Points | 24 points (Sink/Source) | 24 points (Sink/Source) |
Output Points | 24 points (Relay) | 24 points (Transistor, Sink) |
Output Current | 2A per point (Resistive load) | 0.5A per point |
Program Memory | 16k steps | 16k steps |
Data Memory | 10k words | 10k words |
High-Speed Counters | 4 points (single-phase 20kHz) | 4 points (single-phase 20kHz) |
Pulse Output | 2 points (20kHz) | 2 points (20kHz) |
Communication Ports | RS-232 x1, RS-485 x1 | RS-232 x1, RS-485 x1 |
Operating Temperature | 0°C to 55°C | 0°C to 55°C |
Dimensions (WxHxD) | 260mm x 90mm x 81mm | 260mm x 90mm x 81mm |
Weight | Approx. 1.2 kg | Approx. 1.2 kg |
Common Standards: CE, UL, RoHS compliant
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty
- Technical support for configuration and programming (ISPSoft software)
- Wiring and system integration assistance
- Compatibility verification with Delta HMI and drives
- Commissioning and diagnostics support available
Delivery Time
- Standard delivery: 3-5 working days
- Express shipping available upon request
Why Choose Our Store
- Genuine DELTA components
- Global supply network with competitive pricing
- Expertise in industrial automation and PLC systems
- Comprehensive technical documentation and manuals
- Responsive customer service and support
Applications
- Medium-scale Machine Control: Automated assembly lines, testing equipment
- Material Handling: Conveyor control systems, sorting machines
- Packaging Machinery: Filling, capping, and labeling machines
- Process Automation: Batch processing, mixing systems
- Building Automation: Control panels for HVAC, lighting, and access
