Description
The AIRTAC ACE series is a comprehensive line of compact air cylinders designed to save space and improve efficiency in industrial automation. The ACE32X100B is a representative model with a 32mm bore and 100mm stroke. This series covers multiple bore sizes (12mm, 16mm, 20mm, 25mm, 32mm) and stroke lengths (5mm, 10mm, 30mm, 50mm, 60mm, 70mm, 80mm, 100mm), offering a versatile solution for various pneumatic actuation needs. These cylinders are engineered with a compact, lightweight design that provides up to 50% space savings compared to standard cylinders, making them ideal for machinery and equipment with limited installation space.
Key Features
- Compact Air Cylinder designed for space-saving applications
- Wide Range: Multiple bore sizes (12-32mm) and stroke lengths (5-100mm)
- Space Saving: Compact design reduces installation space by up to 50%
- Easy Installation: Standard mounting patterns and clear sensor groove
- Durable Construction: Hard anodized aluminum tube for enhanced wear resistance
- Country of Origin: China (AIRTAC International Group)
Technical Specifications
Parameter | Specification |
|---|---|
Series | ACE (Compact Air Cylinder) |
Bore Sizes | 12 mm, 16 mm, 20 mm, 25 mm, 32 mm |
Stroke Lengths | 5 mm, 10 mm, 30 mm, 50 mm, 60 mm, 70 mm, 80 mm, 100 mm |
Working Pressure | 0.15 – 1.0 MPa (1.5 – 10 bar) |
Operating Temperature | -20°C to 80°C |
Cushioning | Adjustable pneumatic cushion |
Port Size | Rc1/8, NPT1/8, or G1/8 |
Mounting Style | Various options available |
Material | Aluminum alloy tube, stainless steel piston rod |
Rod End Style | External thread (B series) |
Protection Rating | Standard industrial grade |
Standards | ISO 21287 compliant |
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty
- Technical support for configuration and installation
- Compatibility verification with existing pneumatic systems
- Commissioning and diagnostics support available
Delivery Time
- Standard delivery: 3-5 working days
- Express shipping available upon request
Why Choose Our Store
- Genuine AIRTAC components
- Global supply network with competitive pricing
- Expertise in pneumatic automation systems
- Comprehensive technical documentation
- Responsive customer service and support
Applications
- Automated Production Lines: Positioning, clamping, and ejecting operations
- Material Handling: Conveyor system gates and stops
- Packaging Machinery: Product handling and sorting
- Robotics: End effector actuation
- Machine Tools: Tool clamping and part ejection
- Assembly Equipment: Component insertion and fastening
