How to Select the Right Siemens PLC: A Technical Guide for Industrial Applications
Selecting the right Programmable Logic Controller (PLC) is critical for the efficiency and reliability of your automation system. This guide provides a technical framework for choosing the optimal Siemens PLC model for your project, ensuring performance, scalability, and cost-effectiveness.
Step One : Define Your Control Requirements
The foundation of PLC selection is a thorough understanding of your application’s technical parameters.
I/O Point Count :
The first step is to quantify all inputs (sensors, push buttons, switches) and outputs (motor starters, valves, indicator lights). Always add a 20-30% margin to your final count for future system modifications and expansion.
Application Complexity :
Simple Control (e.g., basic logic, timing): Siemens LOGO! is an affordable logic module ideal for small standalone systems.
Medium Complexity (e.g., motion control, HMI integration, data logging): The Siemens S7-1200 series offers a perfect balance of performance and value.
High Complexity (e.g., advanced process control, high-speed automation): The Siemens S7-1500 series delivers top-tier processing power, security, and connectivity.
Networking & Communication :
Determine if the PLC needs to communicate with HMIs, other PLCs, or enterprise systems. Profinet is the standard industrial Ethernet protocol for Siemens controllers. Legacy systems may require Profibus or serial ports (RS485).
Environmental Conditions:
Consider the installation environment. For harsh industrial environments with dust, moisture, or extreme temperatures,IP65/IP67-rated distributed I/O systems like the Siemens ET 200SP series are required. Standard controllers need to be installed in protected control cabinets.
Step Two : Siemens PLC Series Comparison
Example Model
LOGO! 8 6ED1052-1BB08-2FB1
Product Series
- Siemens LOGO!
- Siemens S7-1200
- Siemens S7-1500
- Siemens ET 200SP
Best For
Small machines, basic applications
Mid-range machines, packaging, conveyors
High-speed, complex automation
High-speed, complex automation
Key Features
Low cost, easy setup, integrated display
Integrated Profinet, strong ecosystem
High performance, advanced diagnostics, security
Modular, IP65 protection, connects via Profinet
Step Three : Avoid These Common PLC Selection Mistakes
Mistake One :
Underestimating I/O Count. Future-proof your system by including a significant I/O margin.
Mistake Two :
Ignoring Power Supply Calculations. Sum the power consumption of the CPU and all expansion modules, then select a power supply with a higher wattage rating. For example, the product SITOP PSU100C 6ES7307-1KA02-0AA0 is a reliable choice for many S7-1200 applications.
Mistake Three :
Choosing Obsolete Technology. Avoid legacy models like the S7-300/400 for new designs. Focus on the future-proof product S7-1200 6es7511-1ak02-0ab0 and S7-1500 families for better support and longevity.
Mistake Four :
Underestimating the Need for Expansion. If your chosen CPU doesn’t have enough I/O, you will need an expansion-modules. A popular choice for the S7-1200 is the SM 1223 6ES7223-1BL32-0XB0 (16 DI / 16 DO).
Step Four : Practical Selection Examples
Example One :
Small Conveyor SystemRequirements: 10 Sensors, 5 Motors, Profinet connectivity.
Selection : A Siemens S7-1200 CPU 1214C provides sufficient I/O. The integrated Profinet port handles communication. To connect the sensors,Analog Input Module 6ES7231-4HD32-0XB0 might be needed.
Example Two :
Harsh Environment Application
Requirements : 20 I/O points located in a dusty, wet area.
Selection : A Siemens ET 200SP distributed I/O station is ideal.You would need a Interface Module 6ES7136-6BA00-0CA0 and a mix of Digital and Analog modules.
