Description
The KEYENCE GL-S12SH is a compact, high-performance Type 4 (SIL 3, PL e) safety light curtain from the GL-S Series. This “Slim Type” model features 12 optical axes with a 20 mm resolution, providing a protection height of 220 mm for finger and hand detection. With a detection range of 0.1 m to 2.0 m and a super-slim housing cross-section of only 15 mm x 30 mm, it is designed for seamless integration into tight spaces on small machinery, robots, and automated cells. It incorporates KEYENCE’s unique One-Line wiring system, built-in muting, and external device monitoring (EDM), eliminating the need for bulky external controllers and simplifying installation.
Key Features
- Safety Light Curtain with 12 optical axes (Slim Type)
- Protection Height: 220 mm
- Detection Range: 0.1 m to 2.0 m
- Resolution (Beam Spacing): 20 mm (Finger Safety)
- Safety Rating: Type 4, SIL 3, PL e (Category 4)
- Output Configuration: PNP (determined by cable type)
- Connection: M12 5-pin connector (Emitter/Receiver)
- Protection Rating: IP65 / IP67
- Operating Temperature: -10°C to +55°C
- Response Time: ≤ 8.7 ms
- Housing Cross-Section: 15 mm x 30 mm (Ultra-Slim)
- Country of Origin: Japan
Technical Specifications
- Supply Voltage: 24 VDC ±20% (Class 2)
- Current Consumption: Max. 350 mA (Emitter + Receiver)
- Output Type: 2 OSSD outputs (PNP via cable)
- Output Current: Max. 500 mA (OSSD), Max. 50 mA (AUX)
- Light Source: Infrared LED
- Minimum Detectable Object: ø25 mm
- Synchronization: Optical (Channel A/B) or Wire (Channel 0)
- Housing Material: Extruded Aluminum
- Dimensions (W×H×D): 15 mm × 220 mm × 30 mm (approx.)
- Weight: Approx. 0.3 kg
- Standards: IEC/EN 61496-1/2, UL 61496-1/2, CE, UL
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty
- Technical support for safety circuit integration (OSSD wiring)
- Assistance with muting, blanking, and EDM (External Device Monitoring) setup
- Compatibility verification with PLC safety inputs
- Alignment and commissioning diagnostics support available
Delivery Time
- Standard delivery: 3-5 working days
- Express shipping available for machine downtime emergencies
Why Choose Our Store
- Genuine KEYENCE components or certified refurbished equivalents
- Expertise in machine safety standards (ISO 13849)
- Supply of mating M12 connectors and quick-fit mounting brackets
- Comprehensive technical documentation (datasheets, manuals)
Applications
- Point-of-operation guarding on small presses and stamping machines
- Hand protection on robotic assembly cells and pick-and-place units
- Perimeter fencing for compact automation equipment
- Material handling and packaging machinery safety in confined spaces
- Replacement for obsolete or damaged GL-S series curtains
