Description
The Siemens SITOP PSU100L Power Supply (6EP1334-1LB00) is a highly efficient and reliable 24V DC power supply unit designed for industrial applications. This compact power supply delivers 3A output current with 72W output power, featuring wide-range input voltage (85-264V AC/120-300V DC) for global deployment. With its robust metal housing, screw terminal connections, and DIN rail mounting, it ensures easy installation and reliable operation in demanding industrial environments. The power supply includes overvoltage, overload, and short-circuit protection, making it ideal for powering PLCs, sensors, actuators, and other automation components.
Key Features
- Industrial power supply with 24V DC/3A, 72W output
- Wide-range input: 85-264V AC/120-300V DC, 47-63 Hz
- High efficiency up to 89.2%
- Metal housing for robust protection
- Screw terminal connections
- DIN rail mounting
- Overvoltage, overload, and short-circuit protection
- LED status indicator (green)
- Country of origin: Germany
Technical Specifications
- Input Voltage: 85-264V AC, 120-300V DC
- Input Frequency: 47-63 Hz
- Output Voltage: 24V DC (adjustable 24-28V)
- Output Current: 3A
- Output Power: 72W
- Efficiency: Up to 89.2%
- Power Factor: ≥0.85 at 230V AC
- Inrush Current: ≤25A at 230V AC
- Protection Features: Overvoltage, overload, short-circuit
- Operating Temperature: -25°C to +70°C (with derating above 60°C)
- Cooling: Natural convection
- Dimensions: 32mm × 124mm × 114mm (W×H×D)
- Weight: approx. 0.8 kg
- Protection Degree: IP20
- Standards: IEC 61131, UL 508, CE, RoHS compliant
Warranty & After-Sales
- Factory new units: 12 months warranty
- Refurbished units: 3-6 months warranty
- Technical support for configuration and integration
- Wiring and installation assistance
- Compatibility verification with existing systems
- Commissioning and diagnostics support available
Delivery Time
- Standard delivery: 3-5 working days
- Express shipping available upon request
Why Choose Our Store
- Genuine Siemens SITOP components
- Global supply network with competitive pricing
- Expertise in industrial power systems
- Comprehensive technical documentation
- Responsive customer service and support
Applications
- PLC and controller power supply
- Sensor and actuator power
- Small machine control systems
- Distributed I/O system power
- Building automation
- Test and measurement equipment
- Industrial control panels
- Laboratory and educational equipment
